90 • Operational Reference Linea Lite GigE Series Camera
Example: CounterStartSource = Line (Edge Base) Example 2
Countermode = OFF
Counter is
IDLE
CounterEnd Event Generated
CounterStartSource =
Line
1
Counter
Trigger Wait
Counter Register
Countermode
=
Active
Counter
Completed
CounterResetSource =
CounterEnd(Itself)
CounterStartSource = Line (Edge Base ) Example 2
Active
ActiveActive
CounterTriggerActivation
=
Falling Edge
Counter STATUS
0
12
85 10
Any Tick in
CounterEventSource
Active
1
1
CounterDuration = 12
0
The Second StartSource Pulse is ignored
Figure 75: Example – CounterStartSource = Line (Edge Base)
