Holding register 40001 is addressed as register 0000 in the data address field of the telegram. The function code field already specifies
a holding register operation. Therefore, the 4XXXX reference is implicit. Holding register 40108 is addressed as register 006Bhex (107
decimal).
Table 43: Coil Register
Coil number Description Signal direction
1–16 Drive control word. Master to follower
17–32 Drive speed or setpoint reference range 0x0–0xFFFF (-200% ...
~200%).
Master to follower
33–48 Drive status word. Follower to master
49–64 Open-loop mode: Drive output frequency.
Closed-loop mode: Drive feedback signal.
Follower to master
Parameter write control (master to slave).
0 = Parameter changes are written to the RAM of the drive.
65
1 = Parameter changes are written to the RAM and EEPROM of
the drive.
Master to follower
66–65536 Reserved. –
Table 44: Drive Control Word (FC Profile)
Coil 0 1
01 Preset reference lsb
02 Preset reference msb
03 DC brake No DC brake
04 Coast stop No coast stop
05 Quick stop No quick stop
06 Freeze frequency No freeze frequency
07 Ramp stop Start
08 No reset Reset
09 No jog Jog
10 Ramp 1 Ramp 2
11 Data not valid Data valid
12 Relay 1 off Relay 1 on
13 Relay 2 off Relay 2 on
14 Set up lsb
15 –
16 No reversing Reversing
Danfoss A/S © 2024.01 AJ435824192086en-000101 / 130R1295 | 103
