Table 45: Drive Status Word (FC Profile)
Coil 0 1
33 Control not ready Control ready
34 Drive not ready Drive ready
35 Coast stop Safety closed
36 No alarm Alarm
37 Not used Not used
38 Not used Not used
39 Not used Not used
40 No warning Warning
41 Not at reference At reference
42 Hand-on mode Auto mode
43 Out of frequency range In frequency range
44 Stopped Running
45 Not used Not used
46 No voltage warning Voltage warning
47 Not in current limit Current limit
48 No thermal warning Thermal warning
Table 46: Address/Registers
Bus address
Bus register
(1)
PLC register Content Access Description
0 1 40001 Reserved – Reserved for legacy frequency con-
verters VLT® 5000 and VLT® 2800.
1 2 40002 Reserved – Reserved for legacy frequency con-
verters VLT® 5000 and VLT® 2800.
2 3 40003 Reserved – Reserved for legacy frequency con-
verters VLT® 5000 and VLT® 2800.
3 4 40004 Free – –
4 5 40005 Free – –
5 6 40006 Modbus config-
uration
Read/Write TCP only. Reserved for Modbus TCP
(parameter 12-28 Store Data Values
and parameter 12-29 Store Always -
stored in, for example, EEPROM).
6 7 40007 Last fault code Read only Fault code received from parameter
database, refer to WHAT 38295 for
details.
104 | Danfoss A/S © 2024.01 AJ435824192086en-000101 / 130R1295
Design Guide | VLT® AutomationDrive FC 360
