DS2400N
3
The Tilt angle is represented by the value T in Figure 34. Position the reader in order
to minimize the Tilt angle.
T
Figure 34 - Tilt Angle
By using the ACB (Advanced Code Builder) software parameter, the tilt angle is less
critical and can be decoded even if the scan line doesn't cross the entire code. See
par. 4.1 or the Help On Line for details.
48
