Datalogic DS2400N User Manual

INDEX
A
Accessories; 24
Advanced Code Builder (ACB); 55
Auxiliary RS232 Interface; 42
C
CE Compliance; viii
Cleaning; 64
Code Verifier; 45
D
Diagnostic Indication; 20
DS2400N Description; 16
E
Electrical Connections; 30
G
General View; ix
Glossary; 70
I
ID-NET™; 18; 38; 52
Inputs; 43
Installation; 25
L
Laser Safety; vii
LEDs; 17
Linear Code Reading; 57
M
Main Serial Interface; 32
Mechanical Installation; 26
Model Description; 23
Mounting DS2400N; 27; 28
Multiplexer; 54
O
Outputs; 45
P
Package Contents; 25
Pass Through; 50
Picket-Fence Mode; 59
Point-to-Point; 49
Positioning; 47
Power Supply; viii; 32
R
Raster; 60
Reading Diagrams; 61
Reading Features; 55
Reading Performance; 60
Reference Documentation; vi
RS232 Interface; 33
RS232 Master/Slave; 51
RS485 Full-Duplex Interface; 35
RS485 Half-Duplex Interface; 36
S
Safety Regulations; vii
Services and Support; vi
T
Technical Features; 68
Tilt Angle Improvement; 57
Troubleshooting; 65
Typical Layouts; 49
W
WEEE Compliance; viii
X
X-PRESS™; 20; 21
74

Datalogic DS2400N Specifications

General

Type	-
Sensor type	Laser
Read rate (max)	1000 reads/s
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), Pharmacode, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	RS-232, RS-485
Connectivity technology	Wired
Input voltage	10 - 30 V
Power source type	DC
Power consumption (typical)	5 W
Certification	IEC
Product color	Blue, Yellow
Housing material	Aluminum
International Protection (IP) code	IP65
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Depth	34 mm
Width	84 mm
Height	68 mm
Weight	330 g
