Enter/Exit Programming Mode Reading Parameters
98 Gryphon™ I GD44XX / GBT4400/GM440X
Stand Mode Indication
This operation is useful for indicating when the reader is in Stand Mode. If enabled, the blue
indicator will blink when Stand Mode scanning is active. If reader detects motion (or removed
from base station for cordless models) and switches out of Stand Mode into Triggered Mode,
blinking will stop until Stand Mode is active again.
Stand Mode Indication = Disable
Stand Mode Indication = Enable
DEFAULT
$CSMFL00(CR)
$CSMFL01(CR)

Datalogic Gryphon I GBT4400 Specifications

General

Wavelength	650 nm
Scanner type	2D
Yaw reading angle	-40 - 40 °
Tilt reading angle	0 - 360 °
Light levels (direct sunlight)	0 - 100000 lx
Input voltage	4.5 - 14.0 V
Battery capacity	2100 mAh
Number of reads per charge	60000
Bluetooth	Yes
Dimensions (WxDxH)	71 x 100 x 181 mm
Certification	China RoHS, EU RoHS, IEC 60825 Class 2
Product color	Black
LED indicators	Charging, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Weight	245 g
