Enter/Exit Programming Mode Aztec Code
204
Gryphon™ I GD44XX
/
GBT4400/GM440X
Aztec Code
Aztec Code Enable / Disable
Enables/disables the ability of the reader to decode Aztec Code labels.
Aztec Code Length Control
This feature specifies either variable length decoding or fixed length decoding for this
symbology.
Variable Length:
For variable length decoding, a minimum and maximum length may be set.
Fixed Length:
For fixed length decoding, two different lengths may be set.
Aztec Code = Disable
Aztec Code = Enable
DEFAULT
$CAZEN00(CR)
$CAZEN01(CR)
Aztec Code Length Control = Variable Length
Aztec Code Length Control = Fixed Length
DEFAULT
$CAZLC00(CR)
$CAZLC01(CR)

Table of Contents

Other manuals for Datalogic Gryphon I GBT4400

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Datalogic Gryphon I GBT4400 and is the answer not in the manual?

Datalogic Gryphon I GBT4400 Specifications

General IconGeneral
Wavelength650 nm
Scanner type2D
Yaw reading angle-40 - 40 °
Tilt reading angle0 - 360 °
Light levels (direct sunlight)0 - 100000 lx
Input voltage4.5 - 14.0 V
Battery capacity2100 mAh
Number of reads per charge60000
BluetoothYes
Dimensions (WxDxH)71 x 100 x 181 mm
CertificationChina RoHS, EU RoHS, IEC 60825 Class 2
Product colorBlack
LED indicatorsCharging, Power
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)0 - 50 °C
Operating relative humidity (H-H)0 - 95 %
Weight and Dimensions IconWeight and Dimensions
Weight245 g
