Enter/Exit Programming Mode RS-232/USB-Com Interfaces

48

Gryphon™ I GD44XX

/

GBT4400/GM440X

Beep On Not on File

This option enables/disables the action of the reader to sound a three beep sequence upon receiving a Not-On-File

(NOF) host command.

Beep On Not On File = Disable

Beep On Not On File = Enable

$CBPNF00(CR)

DEFAULT

$CBPNF01(CR)

Table of Contents
