Code 128 Enter/Exit Programming Mode

Product Reference Guide

145

Code 128 Length Control

This feature specifies either variable length decoding or fixed length decoding for the Code 128

symbology. See page 265 for more information.

Code 128 Length Control = Variable Length

Code 128 Length Control = Fixed Length

DEFAULT

$CC8LC00(CR)

$CC8LC01(CR)
