296
Gryphon™ I GD44XX
/
GBT4400/GM440X
Standard Cable Pinouts
Figure 19, Figure 20 and Table 51 provide standard pinout information for the interface cable.
Figure 19. Standard Cable Pinouts: Handheld
Figure 20. Standard Cable Pinouts: Base Station
The signal descriptions in Table 51 apply to the connector on the reader and are for reference
only.
Pin 10
Cable Clip (Latch)
To Host
Cable
Cable Strain Relief
Bottom of Scanner
Interface Cable Port
Pin 1
4
5
7
6
3
1 2
8
