Gryphon™ I GD44XX
/
GBT4400/GM440X
Base Station Indications (Cordless Models ONLY)
Base Station Button Indicators
*Only for models with UV Counterfeit Money Detector, see page 13 for more details.
INDICATION LEDS
Power-up Complete Yellow LED on
Reader Disabled by the HOST or the communication
with HOST is not established
Yellow LED blinking ~1Hz
Data/labels are transmitted to the HOST Yellow LEDs turned off for 100mSec
Programming Mode Yellow LED blinks quickly
Configuration alignment with the handheld is in
pr
ogress
Red LED blinks quickly
Battery charging in progress Red LED on
Battery charging complete Green LED on
Battery charger error
Green LED and Red LEDs blink alternatively
~1Hz
No handheld is placed on the cradle Red and Green LEDs off
BUTTON PUSH
EVENT
CORDLESS
RED
INDICATOR(**)
GREEN
INDICATOR(**)
Push at power-up
force device connection
(Aladdin)
Off
Slow blink
F
ast blink
< 1 sec (*) UV LED On/Off Off Off
1 to 5 sec Paging Off Fast blink
5 to 10 sec Unlink (Only BT) Off Slow blink
10 to 15 sec Reset Fast blink Off
15 to 20 sec Restore custom defaults Slow blink Off
> 20 sec No action Off Off
