Enter/Exit Programming Mode Batch Features
240 Gryphon™ I GD44XX / GBT4400/GM440X
Batch Features
Batch Mode
This option specifies whether to store labels in the handheld while disconnected from the base.
Options are as follows:
• Disabled — The handheld will not store/batch labels.
• Automatic — The handheld will store labels to RAM when the handheld goes out of
range and is discon
nected from the remote device.
• Manual — The handheld will always store labels to F
lash memory. The user must manu-
ally send the stored labels to the remote device
using a special "batch send" label.
Send Batch
Use this bar code to initiate sending of labels stored in batch memory.
Batch Mode = Disabled
Batch Mode = Automatic
Batch Mode = Manual
DEFAULT
$CBTBM00(CR)
$CBTBM01(CR)
$CBTBM02(CR)
Do not scan an ENTER/EXIT PROGRAMMING MODE label in conjunction
with this bar code.
BatchSend
Send Batch

Datalogic Gryphon I GBT4400 Specifications

General

Wavelength	650 nm
Scanner type	2D
Yaw reading angle	-40 - 40 °
Tilt reading angle	0 - 360 °
Light levels (direct sunlight)	0 - 100000 lx
Input voltage	4.5 - 14.0 V
Battery capacity	2100 mAh
Number of reads per charge	60000
Bluetooth	Yes
Dimensions (WxDxH)	71 x 100 x 181 mm
Certification	China RoHS, EU RoHS, IEC 60825 Class 2
Product color	Black
LED indicators	Charging, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Weight	245 g
