Enter/Exit Programming Mode Keyboard Settings
62 Gryphon™ I GD44XX / GBT4400/GM440X
Caps Lock State
This option specifies the format in which the reader sends character data. This does not apply when an alternate
key encoding keyboard is selected.
Numlock
This option specifies the setting of the NUMLOCK key in the Keyboard Wedge interface.
USB Keyboard Speed
This option specifies the USB poll rate for a USB keyboard.
Caps Lock State = Caps Lock OFF
Caps Lock State = Caps Lock ON
Caps Lock State = AUTO Caps Lock Enable
Numlock = NUMLOCK key unchanged
Numlock = Numlock key toggled
This feature applies ONLY to the USB Keyboard interface.
DEFAULT
$CKBCL00(CR)
$CKBCL01(CR)
$CKBCL02(CR)
DEFAULT
$CKBNL00(CR)
$CKBNL01(CR)

Datalogic Gryphon I GBT4400 Specifications

General

Wavelength	650 nm
Scanner type	2D
Yaw reading angle	-40 - 40 °
Tilt reading angle	0 - 360 °
Light levels (direct sunlight)	0 - 100000 lx
Input voltage	4.5 - 14.0 V
Battery capacity	2100 mAh
Number of reads per charge	60000
Bluetooth	Yes
Dimensions (WxDxH)	71 x 100 x 181 mm
Certification	China RoHS, EU RoHS, IEC 60825 Class 2
Product color	Black
LED indicators	Charging, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Weight	245 g
