Product Reference Guide 17
Chapter 2
Setup
Unpacking
Check carefully to ensure the reader and any accessories ordered are present and undamaged. If
any damage occurred during shipment, contact Datalogic Technical Support. Information is
shown on
page 10 .
KEEP THE PACKAGING. Should the unit ever require s
ervice, it should be returned in its
original shipping container.
Setting Up the Reader
Depending on whether you are using a Corded or BT version of the Gryphon, follow the steps
provided in this section to connect and get your reader up and communicating with its host.
1. Begin by
Installing the Interface Cable (Corded) or Connecting the Base Station (BT)
2. Go to Interface Selection and set the desired interface.
3.
Configure Interface Settings (only if not using factory settings for that interface)
4. Go to
Configuring Other Features (if modifications are needed from factory settings)

Datalogic Gryphon I GBT4400 Specifications

General

Wavelength	650 nm
Scanner type	2D
Yaw reading angle	-40 - 40 °
Tilt reading angle	0 - 360 °
Light levels (direct sunlight)	0 - 100000 lx
Input voltage	4.5 - 14.0 V
Battery capacity	2100 mAh
Number of reads per charge	60000
Bluetooth	Yes
Dimensions (WxDxH)	71 x 100 x 181 mm
Certification	China RoHS, EU RoHS, IEC 60825 Class 2
Product color	Black
LED indicators	Charging, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Weight	245 g
