Enter/Exit Programming Mode Reading Parameters
92 Gryphon™ I GD44XX / GBT4400/GM440X
LED AND BEEPER INDICATORS
Power On Alert
Disables or enables the indication (from the Beeper) that the reader is receiving power.
Good Read: When to Indicate
This feature specifies when the reader will provide indication (beep and/or flash its green LED)
upon successfully reading a bar code.
Power On Alert = Disable (No Audible Indication)
Power On Alert = Power-up Beep
$CBPPU00(CR)
$CBPPU01(CR)
DEFAULT
Indicate Good Read = After Decode
Indicate Good Read = After Transmit
Indicate Good Read =
A
fter CTS goes inactive then active
DEFAULT
$CBPIN00(CR)
$CBPIN01(CR)
$CBPIN02(CR)

Datalogic Gryphon I GBT4400 Specifications

General

Wavelength	650 nm
Scanner type	2D
Yaw reading angle	-40 - 40 °
Tilt reading angle	0 - 360 °
Light levels (direct sunlight)	0 - 100000 lx
Input voltage	4.5 - 14.0 V
Battery capacity	2100 mAh
Number of reads per charge	60000
Bluetooth	Yes
Dimensions (WxDxH)	71 x 100 x 181 mm
Certification	China RoHS, EU RoHS, IEC 60825 Class 2
Product color	Black
LED indicators	Charging, Power
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Weight	245 g
