Product Reference Guide
299
Table 53. Programming Mode Indications
Error Codes
Upon startup, if the reader sounds a long tone, this means the reader has not passed its
automatic Selftest and has entered FRU (Field Replaceable Unit) isolation mode. If the reader is
reset, the sequence will be repeated. The following table describes the LED flashes/beep codes
associated with an error found.
Programming Mode
- The following indications ONLY occur when the reader is in Programming Mode.
Label Program-
ming Mode Entry
A valid programming label has
been scanned
.
LED blinks continuously
Reader sounds four low fre-
quency beeps.
Label Program-
ming Mode
Rejec
tion of Label
A label has been rejected.
N/A
Reader sounds three times at
lowest frequency & current vol-
ume.
Label Program-
ming Mode
A
cceptance of
Partial Label
In cases where multiple labels
must be scanned
to program one
feature, this indication acknowl-
edges each portion as it is suc-
cessfully scanned.
N/A
Reader sounds one short beep
at high
est frequency & current
volume.
Label Program-
ming Mode
A
cceptance of
Programming
Configuration option(s) have
been succ
essfully programmed
via labels and the reader has
exited Programming Mode.
N/A
Reader sounds one high fre-
quency beep and 4 low fre-
quency beeps followed by reset
be
eps.
Label Program-
ming Mode Can-
cel Item Entry
Cancel label has been scanned.
N/A
Reader sounds two times at low
frequency and current volume.
NUMBER OF LED
FLASHES/BEEPS
ERROR
A
ll Models:
GD44XX, GBT4400, GM44XX
CORRECTIVE ACTION
1 Configuration
Contact Helpdesk for assis-
tance
2 Interface PCB
6 Digital PCB
12 Imager
15 Accelerometer
