Deif Multi-line 2 User Manual

AGC Designer’s Reference Handbook
DEIF A/S Page 104 of 168
VDO input 105
This VDO input is used for measuring the cooling water temperature.
VDO sensor
type
Temperature Type 1 Type 2 Type 3 Type 4
°C Ω Ω Ω Ω
40 291.5 480.7 69.3 Point 1
50 197.3 323.6 Point 2
60 134.0 222.5 36.0 Point 3
70 97.1 157.1 Point 4
80 70.1 113.2 19.8 Point 5
90 51.2 83.2 Point 6
100 38.5 62.4 11.7 Point 7
110 29.1 47.6 Point 8
120 22.4 36.8 7.4
130 28.9
140 22.8
150 18.2
Level switch type
VDO sensor type
Type 3
Resistance Function
<1.7kΩ Normal situation, no alarm
>1.7kΩ Alarm situation
VDO input 106
This VDO input is used for the fuel level sensor.
VDO sensor type
Type 1
Value Resistance
0% 78.8Ω
100% 1.6Ω
VDO sensor type
Type 2
Value Resistance
0% 3Ω
100% 180Ω
The configurable type is configurable with 8 points.
If the VDO input is used as a level switch, then be aware that no voltage must be
connected to the input. If any voltage is applied to the VDO inputs, then it will be
damaged. Refer to the Application Notes for further wiring information.
If the VDO input is used as a level switch, then be aware that no voltage must be
connected to the input. If any voltage is applied to the VDO inputs, then it will be
damaged. Refer to the Application Notes for further wiring information.
