AGC Designer’s Reference Handbook
DEIF A/S Page 167 of 168
6260 P
nom
derate
No. Setting Min. setting Max. setting Factory
setting
6261 P
nom
derate Input 4…20mA VDO/PT100 4…20mA
6262 P
nom
derate Start derate 0 20000 16 units
6263 P
nom
derate Derate slope 0.1%/U 100.0%/U 5.0%/U
6264 P
nom
derate Proportional OFF ON OFF
6265 P
nom
derate Enable OFF ON OFF
6266 P
nom
derate Derate limit 0.0% 100.0% 80.0%
6310 Idle running
No. Setting Min. setting Max. setting Factory
setting
6311 Idle running Start timer 0.0 min 999.9 min 300.0 min
6312 Idle running Enable start timer OFF ON OFF
6313 Idle running Stop timer 0.0 min 999.9 min 300.0 min
6314 Idle running Enable stop timer OFF ON OFF
6315 Idle running Idle relay Option dependent R0 (none)
6316 Idle running Enable OFF ON OFF
6400 Master clock
No. Setting Min. setting Max. setting Factory
setting
6401 Master clock Start hour 0 23 8
6402 Master clock Stop hour 0 23 8
6403 Master clock Difference 0.1Hz 1.0Hz 0.1Hz
6404 Master clock Setpoint 1 s 999 s 20 s
6405 Master clock Enable OFF ON OFF
6410 Battery test
No. Setting Min. setting Max. setting Factory
setting
6411 Battery test Setpoint 8.0V DC 32.0V DC 18.0V DC
6412 Battery test Delay 1 s 300 s 20 s
6413 Battery test Output A R0 (none)
6414 Battery test Output B
Option dependent
R0 (none)
6415 Battery test Enable OFF ON OFF
6420 Voltage trip
No. Setting Min. setting Max. setting Factory
setting
6421 Voltage trip Type Phase-phase Phase-neutral Phase-phase
Mains setup
6500 Mains power
No. Setting Min. setting Max. setting Factory
setting
6501 Mains power Day -20000 kW 20000 kW 750 kW
6502 Mains power Night -20000 kW 20000 kW 1000 kW
6503 Mains power Transducer max 0 kW 20000 kW 1500 kW
6504 Mains power Transducer min -20000 kW 0 kW -1500 kW
