Deif Multi-line 2 User Manual

AGC Designer’s Reference Handbook
DEIF A/S Page 164 of 168
6060 Gen-set modes
No. Setting Setting Factory
setting
6061 Gen-set mode Island operation Island operation -
Gen-set mode AMF AMF AMF
Gen-set mode Peak shaving Peak shaving -
Gen-set mode Fixed power Fixed power -
Gen-set mode Mains power export Mains power export -
Gen-set mode Load take over Load take over -
6070 Date and time (internal clock) setting
No. Setting Min. setting Max. setting Factory
setting
6071 Date and time Year 2001 2100
6072 Date and time Month 1 12
6073 Date and time Day 1 31
6074 Date and time Weekday 1 7
6075 Date and time Hour 0 23
6076 Date and time Minute 0 59
Depending on
the software
version
6080 Counters
The settings below (except kWh) are offset values that need to be adjusted at the
commissioning if the display is used for reading the values. A breaker operation is counted each
time the breaker closes.
The setting ‘reset kWh counter’ resets the value of the produced kWh.
No. Setting Min. setting Max. setting Factory
setting
6081 Counters Running time 0 20000 0
6082 Counters GB operations 0 20000 0
6083 Counters MB operations 0 20000 0
6084 Counters kWh OFF ON OFF
6085 Counters Start attempts 0 20000 0
6090 Service timer
The function of the service timer enables the user to get an alarm when service of the gen-set is
needed. The timer is reset when the alarm is acknowledged or when the timer is disabled and
enabled again.
No. Setting Min. setting Max. setting Factory
setting
6091 Service timer Setpoint 0 h 9000 h 500 h
6092 Service timer Relay output A R0 (none) R0 (none)
6093 Service timer Relay output B R0 (none)
Option
dependent
R0 (none)
6094 Service timer Enable OFF ON ON
6095 Service timer Fail class Alarm (1) Trip MB (6) Warning (2)
The date and time can easily be synchronised with the present time and date
from the utility software.
