AGC Designer’s Reference Handbook
DEIF A/S Page 157 of 168
4110 Oil pressure 1 (4…20mA input 100.1)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4111 Oil pressure 1 Setpoint 0 bar 50 bar - 10 bar
4112 Oil pressure 1 Timer 0.0 s 180.0 s - 5.0 s
4113 Oil pressure 1 Relay output A R0 (none) - R0 (none)
4114 Oil pressure 1 Relay output B R0 (none)
Option
dependent
- R0 (none)
4115 Oil pressure 1 Enable OFF ON RUN OFF
4116 Oil pressure 1 Fail class Alarm (1) Trip MB (6) - Warning (2)
4120 Oil pressure 2 (4…20mA input 100.2)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4121 Oil pressure 2 Setpoint 0 bar 50 bar - 10 bar
4122 Oil pressure 2 Timer 0.0 s 180.0 s - 5.0 s
4123 Oil pressure 2 Relay output A R0 (none) - R0 (none)
4124 Oil pressure 2 Relay output B R0 (none)
Option
dependent
- R0 (none)
4125 Oil pressure 2 Enable OFF ON RUN OFF
4126 Oil pressure 2 Fail class Alarm (1) Trip MB (6) - Warning (2)
4130 Fuel level 1 (4…20mA input 102.1)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4131 4…20mA input 102.1 Setpoint 0% 120% - 10%
4132 4…20mA input 102.1 Timer 0.0 s 600.0 s - 120.0 s
4133 4…20mA input 102.1 Relay output A R0 (none) - R0 (none)
4134 4…20mA input 102.1 Relay output B R0 (none)
Option
dependent
- R0 (none)
4135 4…20mA input 102.1 Enable OFF ON RUN OFF
4136 4…20mA input 102.1 Fail class Alarm (1) Trip MB (6) - Warning (2)
4140 Fuel level 2 (4…20mA input 102.2)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4141 4…20mA input 102.2 Setpoint 0% 120% - 10%
4142 4…20mA input 102.2 Timer 0.0 s 600.0 s - 120.0 s
4143 4…20mA input 102.2 Relay output A R0 (none) - R0 (none)
4144 4…20mA input 102.2 Relay output B R0 (none)
Option
dependent
- R0 (none)
4145 4…20mA input 102.2 Enable OFF ON RUN OFF
4146 4…20mA input 102.2 Fail class Alarm (1) Trip MB (6) - Warning (2)
4150 4…20mA input 104.1 (option M1)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4151 4…20mA input 104.1 Setpoint 4mA 20mA - 10mA
4152 4…20mA input 104.1 Timer 0.2 s 100.0 s - 10.0 s
4153 4…20mA input 104.1 Relay output A R0 (none) - R0 (none)
4154 4…20mA input 104.1 Relay output B R0 (none)
Option
dependent
- R0 (none)
4155 4…20mA input 104.1 Enable OFF ON RUN OFF
4156 4…20mA input 104.1 Fail class Alarm (1) Trip MB (6) - Warning (2)
