Deif Multi-line 2 User Manual

AGC Designer’s Reference Handbook
DEIF A/S Page 158 of 168
4160 4…20mA input 104.2 (option M1)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4161 4…20mA input 104.2 Setpoint 4mA 20mA - 10mA
4162 4…20mA input 104.2 Timer 0.2 s 100.0 s - 10.0 s
4163 4…20mA input 104.2 Relay output A R0 (none) - R0 (none)
4164 4…20mA input 104.2 Relay output B R0 (none)
Option
dependent
- R0 (none)
4165 4…20mA input 104.2 Enable OFF ON RUN OFF
4166 4…20mA input 104.2 Fail class Alarm (1) Trip MB (6) - Warning (2)
4170 VDO 104.1 (option M2)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4171 VDO 104.1 Setpoint 0.0 bar 10.0 bar - 4.0 bar
4172 VDO 104.1 Timer 0.0 s 100.0 s - 5.0 s
4173 VDO 104.1 Relay output A R0 (none) - R0 (none)
4174 VDO 104.1 Relay output B R0 (none)
Option
dependent
- R0 (none)
4175 VDO 104.1 Enable OFF ON RUN OFF
4176 VDO 104.1 Fail class Alarm (1) Trip MB (6) - Warning (2)
4180 VDO 104.2 (option M2)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4181 VDO 104.2 Setpoint 0.0 bar 10.0 bar - 5.0 bar
4182 VDO 104.2 Timer 0.0 s 100.0 s - 5.0 s
4183 VDO 104.2 Relay output A R0 (none) - R0 (none)
4184 VDO 104.2 Relay output B R0 (none)
Option
dependent
- R0 (none)
4185 VDO 104.2 Enable OFF ON RUN OFF
4186 VDO 104.2 Fail class Alarm (1) Trip MB (6) - Trip/stop (4)
4190 VDO 105.1 (option M2)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4191 VDO 105.1 Setpoint 40 deg. 150 deg. - 100 deg.
4192 VDO 105.1 Timer 0.0 s 100.0 s - 5.0 s
4193 VDO 105.1 Relay output A R0 (none) - R0 (none)
4194 VDO 105.1 Relay output B R0 (none)
Option
dependent
- R0 (none)
4195 VDO 105.1 Enable OFF ON RUN OFF
4196 VDO 105.1 Fail class Alarm (1) Trip MB (6) - Warning (2)
4200 VDO 105.2 (option M2)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4201 VDO 105.2 Setpoint 40 deg. 150 deg. - 110 deg.
4202 VDO 105.2 Timer 0.0 s 100.0 s - 5.0 s
4203 VDO 105.2 Relay output A R0 (none) - R0 (none)
4204 VDO 105.2 Relay output B R0 (none)
Option
dependent
- R0 (none)
4205 VDO 105.2 Enable OFF ON RUN OFF
4206 VDO 105.2 Fail class Alarm (1) Trip MB (6) - Trip/stop (4)
