Deif Multi-line 2 User Manual

AGC Designer’s Reference Handbook
DEIF A/S Page 159 of 168
4210 VDO 106.1 (option M2)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4211 VDO 106.1 Setpoint 0% 100% - 10%
4212 VDO 106.1 Timer 0.0 s 100.0 s - 10.0 s
4213 VDO 106.1 Relay output A R0 (none) - R0 (none)
4214 VDO 106.1 Relay output B R0 (none)
Option
dependent
- R0 (none)
4215 VDO 106.1 Enable OFF ON RUN OFF
4216 VDO 106.1 Fail class Alarm (1) Trip MB (6) - Warning (2)
4220 VDO 106.2 (option M2)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4221 VDO 106.2 Setpoint 0% 100% - 5%
4222 VDO 106.2 Timer 0.0 s 100.0 s - 10.0 s
4223 VDO 106.2 Relay output A R0 (none) - R0 (none)
4224 VDO 106.2 Relay output B R0 (none)
Option
dependent
- R0 (none)
4225 VDO 106.2 Enable OFF ON RUN OFF
4226 VDO 106.2 Fail class Alarm (1) Trip MB (6) - Trip/stop (4)
4240 Water temperature (PT100 input 106 - setpoint 1) (option M1)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4241 Water temp. Setpoint -40°C 250°C - 80°C
4242 Water temp. Timer 0.0 s 180.0 s - 5.0 s
4243 Water temp. Relay output A R0 (none) - R0 (none)
4244 Water temp. Relay output B R0 (none)
Option
dependent
- R0 (none)
4245 Water temp. Enable OFF ON RUN OFF
4246 Water temp. Fail class Alarm (1) Trip MB (6) - Warning (2)
4260 PT100 input 109.1 (option M1)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4261 PT100 input 109 Setpoint -40°C 250°C - 80°C
4262 PT100 input 109 Timer 0.2 s 100.0 s - 10.0 s
4263 PT100 input 109 Relay output A R0 (none) - R0 (none)
4264 PT100 input 109 Relay output B R0 (none)
Option
dependent
- R0 (none)
4265 PT100 input 109 Enable OFF ON RUN OFF
4266 PT100 input 109 Fail class Alarm (1) Trip MB (6) - Warning (2)
4300 Running detection
This setpoint is used to define the level where the gen-set is recognised as running. When this
RPM level is reached, the automatic running detection is enabled
(6150 Running status
)
.
Also take notice of the menu ‘remove starter’ setpoint (6160 Remove starter).
No. Setting Min. setting Max. setting Factory
setting
4301 Running detection Setpoint 1 RPM 4000 RPM 1000 RPM
4302 Running detection Type Frequency detection X
Running detection Type Tacho
Running detection Type Binary input
Running detection Type Engine I/F communication
