Deif Multi-line 2 User Manual

AGC Designer’s Reference Handbook
DEIF A/S Page 160 of 168
4310 Overspeed 1
No. Setting Min. setting Max. setting Factory
setting
4311 Overspeed 1 Setpoint 1 RPM 4000 RPM 1450 RPM
4312 Overspeed 1 Timer 0.0 s 100.0 s 5.0 s
4313 Overspeed 1 Relay output A R0 (none) R0 (none)
4314 Overspeed 1 Relay output B R0 (none)
Option
dependent
R0 (none)
4315 Overspeed 1 Enable OFF ON OFF
4316 Overspeed 1 Fail class Alarm (1) Trip MB (6) Warning (2)
4320 Overspeed 2
No. Setting Min. setting Max. setting Factory
setting
4321 Overspeed 2 Setpoint 1 RPM 4000 RPM 1750 RPM
4322 Overspeed 2 Timer 0.0 s 100.0 s 1.0 s
4323 Overspeed 2 Relay output A R0 (none) R0 (none)
4324 Overspeed 2 Relay output B R0 (none)
Option
dependent
R0 (none)
4325 Overspeed 2 Enable OFF ON OFF
4326 Overspeed 2 Fail class Alarm (1) Trip MB (6) Shutdown (5)
4370 Wire failure analogue input 98 (M1 and M2)
No. Setting Min. setting Max. setting Factory
setting
4371 W. fail. ana. 98 Output A R0 (none) R0 (none)
4372 W. fail. ana. 98 Output B R0 (none)
Option
dependent
R0 (none)
4373 W. fail. ana. 98 Enable OFF ON OFF
4374 W. fail. ana. 98 Fail class Alarm (1) Trip MB (6) Warning (2)
4380 Wire failure analogue input 100 (M1 and M2)
No. Setting Min. setting Max. setting Factory
setting
4381 W. fail. ana. 100 Output A R0 (none) R0 (none)
4382 W. fail. ana. 100 Output B R0 (none)
Option
dependent
R0 (none)
4383 W. fail. ana. 100 Enable OFF ON OFF
4384 W. fail. ana. 100 Fail class Alarm (1) Trip MB (6) Warning (2)
4390 Wire failure analogue input 102 (M1 and M2)
No. Setting Min. setting Max. setting Factory
setting
4391 W. fail. ana. 102 Output A R0 (none) R0 (none)
4392 W. fail. ana. 102 Output B R0 (none)
Option
dependent
R0 (none)
4393 W. fail. ana. 102 Enable OFF ON OFF
4394 W. fail. ana. 102 Fail class Alarm (1) Trip MB (6) Warning (2)
4400 Wire failure analogue input 104 (M1)
No. Setting Min. setting Max. setting Factory
setting
4401 W. fail. ana. 104 Output A R0 (none) R0 (none)
4402 W. fail. ana. 104 Output B R0 (none)
Option
dependent
R0 (none)
4403 W. fail. ana. 104 Enable OFF ON OFF
4404 W. fail. ana. 104 Fail class Alarm (1) Trip MB (6) Warning (2)
