AGC Designer’s Reference Handbook
DEIF A/S Page 26 of 168
Flowcharts
Using flowcharts, the principles of the most important functions will be illustrated in the next
sections. The functions included are:
• Mode shift
• MB open sequence
• GB open sequence
• Stop sequence
• Start sequence
• MB close sequence
• GB close sequence
• Fixed power
• Load take over
• Island operation
• Peak shaving
• Mains power export
• Automatic Mains Failure
• Test sequence
The flowcharts below are for guidance only. For illustrative purposes the
flowcharts are simplified in some extent.
