AGC Designer’s Reference Handbook
DEIF A/S Page 151 of 168
2020 Dynamic synchronisation
No. Setting Min. setting Max. setting Factory
setting
2021 Dynamic sync. df max. 0.0Hz 0.5Hz 0.3Hz
2022 Dynamic sync. df min. -0.5Hz 0.5Hz 0.0Hz
2023 Dynamic sync. dU max. 2% 10% 5%
2024 Dynamic sync. Breaker delay 40 ms 300 ms 50 ms
2030 Static synchronisation
No. Setting Min. setting Max. setting Factory
setting
2031 Static sync. Maximum df 0.00Hz 0.50Hz 0.10Hz
2032 Static sync. Maximum dU 2% 10% 5%
2033 Static sync. Close window 0.1 deg. 20.0 deg. 10.0 deg.
2034 Static sync. Phase K
P
0 1000 10
2035 Static sync. Phase K
I
0 1000 10
2040 Sync. blackout
No. Setting Min. setting Max. setting Factory
setting
2041 Sync. blackout df max. 0.0Hz 5.0Hz 3.0Hz
2042 Sync. blackout dU max. 2% 10% 5%
Settings are accepted limits (generator voltage and frequency) for closing the generator and
mains breaker. The values are according to nominal values.
Example:
f
NOM
and U
NOM
= 50 Hertz and 400 volts.
With factory settings the breaker is able to close, if the frequency is between 47 and 53 Hertz
and the voltage is between 380 and 420 volts.
2070 GB general failure
- Synchronisation time Adjustable time delay channel 2071
- Breaker ON/OFF feedback fail. 1 second fixed time delay
- Phase sequence error 1 second fixed time delay
No. Setting Min. setting Max. setting Factory
setting
2071 GB general fail. Delay 30.0 s 300.0 s 60.0 s
2072 GB general fail. Relay output A R0 (none) R0 (none)
2073 GB general fail. Relay output B R0 (none)
Option
dependent
R0 (none)
The general failure alarms cannot be disabled.
2080 MB general failure
- Synchronisation time Adjustable time delay channel 2081
- Breaker ON/OFF feedback fail. 1 second fixed time delay
- Phase sequence error 1 second fixed time delay
