AGC Designer’s Reference Handbook
DEIF A/S Page 97 of 168
Digital inputs
The unit has a number of binary inputs some of which are configurable and some are not. The
number of digital inputs on the standard unit depends on the selected engine interface card.
Engine interface card Available digital inputs
– not configurable
Available digital inputs
– configurable
M1 (standard) 2 3
M2 (option) 2 7
Input function Auto Semi Test Man Block Configurable Input
type
1 Fire pump X X X X Configurable Constant
2 Access lock X X X X X Not configurable Constant
3 Running feedback X X X X Not configurable Constant
4 Remote start X X Configurable Pulse
5 Remote stop X X Configurable Pulse
6 Semi-auto X X X X Configurable Pulse
7 Test X X X X Configurable Pulse
8 Auto X X X X Configurable Pulse
9 Manual X X X Configurable Pulse
10 Block X X X X Configurable Constant
11 Remote GB ON X Configurable Pulse
12 Remote GB OFF X Configurable Pulse
13 Remote MB ON X Configurable Pulse
14 Remote MB OFF X Configurable Pulse
15 Remote alarm
acknowledge
X X X X X Configurable Constant
16 Auto start/stop X Configurable Constant
17 Remove starter X X X X Configurable Constant
18 Reset analogue
GOV/AVR outputs
X X X X Configurable Pulse
19 Manual GOV up X Configurable Constant
20 Manual GOV down X Configurable Constant
21 Manual AVR up X Configurable Constant
22 Manual AVR down X Configurable Constant
23 Alarm inhibit X X X X X Not configurable Constant
24 GB position ON X X X X X Not configurable Constant
25 GB position OFF X X X X X Not configurable Constant
26 MB position ON X X X X X Not configurable Constant
27 MB position OFF X X X X X Not configurable Constant
28 Emergency stop X X X X X Text
configurable
Constant
29 External engine
failure
X X X X X Text
configurable
Constant
30 Low speed X X X Configurable Constant
31 Temperature
control
X X X Configurable Constant
32 Battery test X Configurable Pulse
33 Mains OK X X X X X Configurable Constant
34 External f control X X X Configurable Constant
35 External P control X X X Configurable Constant
36 External PF
control
X X X Configurable Constant
37 External U control X X X Configurable Constant
