Deif Multi-line 2 User Manual

AGC Designer’s Reference Handbook
DEIF A/S Page 98 of 168
Input function Auto Semi Test Man Block Configurable Input
type
38 External Q power X X X Configurable Constant
39 Print status X X X Configurable Pulse
40 Print event log X X X Configurable Pulse
41 MB close inhibit X X X X X Configurable Constant
42 Engine comm.
inhibit
X X X X X Configurable Constant
43 Enable mode shift X Configurable Constant
44 Enable GB black
close
X X X X X Configurable Constant
45 Enable sep. sync. X X X X X Configurable Constant
46 Custom alarm
inhibit
X X X X X Configurable Constant
47 Start enable X X X X NA Configurable Constant
48 GB spring loaded X X X Configurable Constant
49 MB spring loaded X X X Configurable Constant
Functional description
1. Fire pump
This input deactivates all protections except the overspeed protection and the emergency stop
input. The number of start attempts is 7 by default, but it can be configured in
6180 Start
attempts
. Also a special cool down timer is used in the stop sequence after an activation of this
input.
2. Access lock
Activating the access lock input deactivates the control display push-buttons. It will only be
possible to view measurements, alarms and the log.
3. Running feedback
The input is used as a running indication of the engine. When the input is activated, the start
relay is deactivated.
4. Remote start
This input initiates the start sequence of the gen-set when semi-auto or manual mode is
selected.
5. Remote stop
This input initiates the stop sequence of the gen-set when semi-auto or manual mode is
selected. The gen-set will stop without cooling-down.
6. Semi-auto
Changes the present running mode to semi-auto.
7. Test
Changes the present running mode to test.
8. Auto
Changes the present running mode to auto.
9. Manual
Changes the present running mode to manual.
