AGC Designer’s Reference Handbook
DEIF A/S Page 63 of 168
The test sequence will start when the test mode is selected.
Manual
When manual mode is selected, the binary increase/decrease inputs can be used (if they have
been configured) as well as the start and stop push-buttons. When starting in manual mode, the
gen-set will start without any subsequent regulation.
Block
When the block mode is selected, the unit is not able to initiate any sequences, e.g. the start
sequence.
Mode selection
The following drawings illustrate how the mode selection is carried out.
Pushing the MODE push-button will change the displayed text. After pushing ‘MODE’, the fourth
display line indicates the selectable modes. In the third display line, the underscored (fourth line)
selection will be displayed.
Two possibilities are now available:
If ‘BACK’ is pushed, the display returns to the original text without changing the mode.
AGC V. 2.10.0
2005-01-01 13 : 45 : 18
SETUP MENU
SETUP
V3 V2 V1
1. push
‘MODE’
Æ
AGC V. 2.10.0
2005-01-01 13 : 45 : 18
SEMI-AUTO MODE
SEMI
TST AUT MAN BLK
2. push
‘BACK’
Æ
or
G 0 0 0V
f-L1 0.00Hz
PROTECTION SETUP
PROT CTRL
I/O SYST
1. push
‘MODE’
Æ
G 0 0 0V
f-L1 0.00Hz
SEMI-AUTO MODE
SEMI TST AUT MAN BLK
2. push
‘BACK’
Æ
If ‘SEL’ is pushed, the underlined mode is selected, and the display returns to the original text. In
this example the SEMI-AUTO mode is selected.
AGC V. 2.10.0
2005-01-01 13 : 45 : 18
SETUP MENU
SETUP
V3 V2 V1
3. push
‘MODE’
Æ
AGC V. 2.10.0
2005-01-01 13 : 45 : 18
SEMI-AUTO MODE
SEMI
TST AUT MAN BLK
4. push
‘SEL’
Æ
or
G 0 0 0V
f-L1 0.00Hz
PROTECTION SETUP
PROT CTRL
I/O SYST
3. push
‘MODE’
Æ
G 0 0 0V
f-L1 0.00Hz
SEMI-AUTO MODE
SEMI TST AUT MAN BLK
4. push
‘SEL’
Æ
Block mode must be selected, when maintenance work is carried out on the gen-
set.
