AGC Designer’s Reference Handbook
DEIF A/S Page 119 of 168
This diagram illustrates the programme sequence with the M-logic enabled - M-logic is part of
the programme sequence.
GSM communication
The GSM modem communication is used to send a GSM message to up to 5 cellular
telephones when an alarm appears on the display.
System single-line diagram
AGC program sequence
M-logic Input event Output event
Please refer to the ‘M-logic Handbook’ for a full description of this configuration
tool.
DEIF recommends using a MOXA OnCell G2150I, Wavecom WMOD2 or
Westermo GDW-11 terminal, as the application has been tested with these
terminals.
AGC
GSM
Modem
External
antenna
