Deif Multi-line 2 User Manual

AGC Designer’s Reference Handbook
DEIF A/S Page 161 of 168
4410 Wire failure VDO input 104 (M2)
No. Setting Min. setting Max. setting Factory
setting
4411 W. fail. VDO 104 Max. 60% 100% 100%
4412 W. fail. VDO 104 Min. 0% 40% 0%
4413 W. fail. VDO 104 Output A R0 (none) R0 (none)
4414 W. fail. VDO 104 Output B R0 (none)
Option
dependent
R0 (none)
4415 W. fail. VDO 104 Enable OFF ON OFF
4416 W. fail. VDO 104 Fail class Alarm (1) Trip MB (6) Warning (2)
4410 Wire failure PT100 input 106 (M1)
No. Setting Min. setting Max. setting Factory
setting
4411 W. fail. PT100 106 Max. 60% 100% 100%
4412 W. fail. PT100 106 Min. 0% 40% 0%
4413 W. fail. PT100 106 Output A R0 (none) R0 (none)
4414 W. fail. PT100 106 Output B R0 (none)
Option
dependent
R0 (none)
4415 W. fail. PT100 106 Enable OFF ON OFF
4416 W. fail. PT100 106 Fail class Alarm (1) Trip MB (6) Warning (2)
4420 Wire failure VDO input 105 (M2)
No. Setting Min. setting Max. setting Factory
setting
4421 W. fail. VDO 105 Max. 60% 100% 100%
4422 W. fail. VDO 105 Min. 0% 40% 0%
4423 W. fail. VDO 105 Output A R0 (none) R0 (none)
4424 W. fail. VDO 105 Output B R0 (none)
Option
dependent
R0 (none)
4425 W. fail. VDO 105 Enable OFF ON OFF
4426 W. fail. VDO 105 Fail class Alarm (1) Trip MB (6) Warning (2)
4420 Wire failure PT100 input 109 (M1)
No. Setting Min. setting Max. setting Factory
setting
4421 W. fail. PT100 109 Max. 60% 100% 100%
4422 W. fail. PT100 109 Min. 0% 40% 0%
4423 W. fail. PT100 109 Output A R0 (none) R0 (none)
4424 W. fail. PT100 109 Output B R0 (none)
Option
dependent
R0 (none)
4425 W. fail. PT100 109 Enable OFF ON OFF
4426 W. fail. PT100 109 Fail class Alarm (1) Trip MB (6) Warning (2)
4430 Wire failure VDO input 106 (M2)
No. Setting Min. setting Max. setting Factory
setting
4431 W. fail. VDO 106 Max. 60% 100% 100%
4432 W. fail. VDO 106 Min. 0% 40% 0%
4433 W. fail. VDO 106 Output A R0 (none) R0 (none)
4434 W. fail. VDO 106 Output B R0 (none)
Option
dependent
R0 (none)
4435 W. fail. VDO 106 Enable OFF ON OFF
4436 W. fail. VDO 106 Fail class Alarm (1) Trip MB (6) Warning (2)
