Deif Multi-line 2 User Manual

AGC Designer’s Reference Handbook
DEIF A/S Page 150 of 168
Protection
1010 Reverse power
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
1011 Reverse power Setpoint -50.0% 0.0% - -5.0%
1012 Reverse power Timer 0.1 s 100.0 s - 10.0 s
1013 Reverse power Relay output A R0 (none) - R0 (none)
1014 Reverse power Relay output B R0 (none)
Option
dependent
- R0 (none)
1015 Reverse power Enable OFF ON RUN ON
1016 Reverse power Fail class Alarm (1) Trip MB (6) - Trip GB (3)
1020 Overcurrent 1
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
1021 Overcurrent 1 Setpoint 50.0% 200.0% - 115.0%
1022 Overcurrent 1 Timer 0.1 s 100.0 s - 10.0 s
1023 Overcurrent 1 Relay output A R0 (none) - R0 (none)
1024 Overcurrent 1 Relay output B R0 (none)
Option
dependent
- R0 (none)
1025 Overcurrent 1 Enable OFF ON RUN ON
1026 Overcurrent 1 Fail class Alarm (1) Trip MB (6) - Warning (2)
1030 Overcurrent 2
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
1031 Overcurrent 2 Setpoint 50.0% 200.0% - 120.0%
1032 Overcurrent 2 Timer 0.1 s 100.0 s - 5.0 s
1033 Overcurrent 2 Relay output A R0 (none) - R0 (none)
1034 Overcurrent 2 Relay output B R0 (none)
Option
dependent
- R0 (none)
1035 Overcurrent 2 Enable OFF ON RUN ON
1116 Overcurrent 2 Fail class Alarm (1) Trip MB (6) - Trip GB (3)
Control
This setup menu consists of the synchronisation setup and the regulation setup.
Synchronisation
2010 Synchronisation type
No. Setting First setting Second
setting
Factory
setting
2011 Sync. type Sync. type Static sync. Dynamic
sync.
Dynamic
sync.
If dynamic synchronisation is chosen, the next menu will be
2020 Dynamic synchronisation
. If static synchronisation is chosen, the next menu will be 2030 Static synchronisation .
