Deif Multi-line 2 User Manual

AGC Designer’s Reference Handbook
DEIF A/S Page 156 of 168
3330 Ext. emergency stop (binary input 117)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
3331 Emergency STOP Timer 0.0 s 60.0 s - 0.0 s
3332 Emergency STOP Relay output A R0 (none) - R0 (none)
3333 Emergency STOP Relay output B R0 (none)
Option
dependent
- R0 (none)
3334 Emergency STOP Enable OFF ON RUN OFF
3335 Emergency STOP Fail class Alarm (1) Trip MB (6) - Shutdown (5)
3336 Emergency STOP Type N/O N/C - N/O
3340 Dig. input no. 118
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
3341 Dig. input no. 118 Timer 0.0 s 100.0 s - 10.0 s
3342 Dig. input no. 118 Relay output A R0 (none) - R0 (none)
3343 Dig. input no. 118 Relay output B R0 (none)
Option
dependent
- R0 (none)
3344 Dig. input no. 118 Enable OFF ON RUN OFF
3345 Dig. input no. 118 Fail class Alarm (1) Trip MB (6) - Warning (2)
3346 Dig. input no. 118 Type N/O N/C - N/O
Analogue input setup
4090 4…20mA input 98.1
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4091 4…20mA input 98.1 Setpoint 4mA 20mA - 10mA
4092 4…20mA input 98.1 Timer 0.0 s 600.0 s - 120.0 s
4093 4…20mA input 98.1 Relay output A R0 (none) - R0 (none)
4094 4…20mA input 98.1 Relay output B R0 (none)
Option
dependent
- R0 (none)
4095 4…20mA input 98.1 Enable OFF ON RUN OFF
4096 4…20mA input 98.1 Fail class Alarm (1) Trip MB (6) - Warning (2)
4100 4…20mA input 98.2
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
4101 4…20mA input 98.2 Setpoint 4mA 20mA - 10mA
4102 4…20mA input 98.2 Timer 0.0 s 600.0 s - 120.0 s
4103 4…20mA input 98.2 Relay output A R0 (none) - R0 (none)
4104 4…20mA input 98.2 Relay output B R0 (none)
Option
dependent
- R0 (none)
4105 4…20mA input 98.2 Enable OFF ON RUN OFF
4106 4…20mA input 98.2 Fail class Alarm (1) Trip MB (6) - Warning (2)
The input is not configurable in the peak shaving mode, load takeover mode and
mains power export, because it is used as a mains power input.
The input is not configurable in the peak shaving mode, load takeover mode and
mains power export, because it is used as a mains power input.
