AGC Designer’s Reference Handbook
DEIF A/S Page 155 of 168
3280 Dig. input no. 112 (option M2)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
3281 Dig. input no. 112 Timer 0.0 s 100.0 s - 10.0 s
3282 Dig. input no. 112 Relay output A R0 (none) - R0 (none)
3283 Dig. input no. 112 Relay output B R0 (none)
Option
dependent
- R0 (none)
3284 Dig. input no. 112 Enable OFF ON RUN OFF
3285 Dig. input no. 112 Fail class Alarm (1) Trip MB (6) - Warning (2)
3286 Dig. input no. 112 Type N/O N/C - N/O
3290 Dig. input no. 113 (option M2)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
3291 Dig. input no. 113 Timer 0.0 s 100.0 s - 10.0 s
3292 Dig. input no. 113 Relay output A R0 (none) - R0 (none)
3293 Dig. input no. 113 Relay output B R0 (none)
Option
dependent
- R0 (none)
3294 Dig. input no. 113 Enable OFF ON RUN OFF
3295 Dig. input no. 113 Fail class Alarm (1) Trip MB (6) - Warning (2)
3296 Dig. input no. 113 Type N/O N/C - N/O
3300 Access lock (binary input 114)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
3301 Access lock Timer 0.0 s 180.0 s - 10.0 s
3302 Access lock Relay output A R0 (none) - R0 (none)
3303 Access lock Relay output B R0 (none)
Option
dependent
- R0 (none)
3304 Access lock Enable OFF ON RUN OFF
3305 Access lock Fail class Alarm (1) Trip MB (6) - Warning (2)
3306 Access lock Type N/O N/C - N/O
3310 Running feedback (binary input 115)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
3311 Run. feedback Timer 0.0 s 180.0 s - 10.0 s
3312 Run. feedback Relay output A R0 (none) - R0 (none)
3313 Run. feedback Relay output B R0 (none)
Option
dependent
- R0 (none)
3314 Run. feedback Enable OFF ON RUN OFF
3315 Run. feedback Fail class Alarm (1) Trip MB (6) - Warning (2)
3316 Run. feedback Type N/O N/C - N/O
3320 Ext. engine failure (binary input 116)
No. Setting Min.
setting
Max.
setting
Third
setting
Factory
setting
3321 Engine failure Timer 0.0 s 180.0 s - 10.0 s
3322 Engine failure Relay output A R0 (none) - R0 (none)
3323 Engine failure Relay output B R0 (none)
Option
dependent
- R0 (none)
3324 Engine failure Enable OFF ON RUN OFF
3325 Engine failure Fail class Alarm (1) Trip MB (6) - Shutdown (5)
3326 Engine failure Type N/O N/C - N/O
