Deif Multi-line 2 User Manual

AGC Designer’s Reference Handbook
DEIF A/S Page 170 of 168
9120 Service menu
The service menu can only be entered using the ‘JUMP’ push-button. This menu is used in
service situations.
In the alarm selection you can see all the alarm timers and their remaining time if they are
counting.
The input and output selections show the present status of the inputs and outputs. E.g. mode
inputs, relay outputs and load sharing lines.
No. Setting Description
9121 Service menu Alarm Shows remaining alarm delay time
9122 Service menu Digital input Shows digital input status
9123 Service menu Digital output Shows digital output status
9124 Service menu Miscellaneous Shows miscellaneous information
9130 Single phase/split phase/three phase
No. Setting Description
9131 Mode Mode 0 = Three phase system
1 = Split phase system
2 = Single phase system
DEIF A/S reserves the right to change any of the above.
