AGC Designer’s Reference Handbook
DEIF A/S Page 77 of 168
Optional protections
Custom inhibit input
configured
Input
Alarm limit
exceeded
and custom
inhibit
enabled
Input OFF Comment
Option A1 -
Active
Option A2 -
Active
Option A3 -
Active
Option A4 -
Active
Option B1 -
Active
Option C1 -
Active
Option C2 -
Active
If an alarm is configured to activate a limit relay, the relay will activate in spite of
the fact that the inhibit input is ON.
If the protection is configured to ‘RUN’ or ‘PARALLEL’ the custom inhibit will
overrule these functions, if the input is active after the conditions for ‘RUN’ or
‘PARALLEL’ have been removed.
Function inputs such as running feedback, remote start or access lock are never
inhibited. Only alarm inputs can be inhibited.
