You can now choose to do one of the following:
• Select a pre-configured curve.
• Select a new custom curve.
• Select or edit an existing custom curve.
CAUTION
You can reuse any previously created custom curve on any terminal(s). However, the configuration settings are the same
across all the other I/O terminals. If you alter the settings for a curve, this will apply to all other I/O terminals where the
curve has been used.
Select a pre-configured curve
INFO
If available, you can select a pre-configured curve, for example VDO 5. Details for the curve are shown on the right, and
you cannot modify a pre-configured curve.
1. Highlight the pre-configured curve, by pressing Up or Down .
2. Select the pre-configured curve, by pressing OK
.
• The selected curve is shown with a solid box.
OPERATOR'S MANUAL 4189341099G UK Page 70 of 130
