Dell 2335dn - Duplex Jam

While pushing the fuser lever to the right, open the fuser door.7.
NOTE: Ensure that to unfold the duplex guide before opening the fuser door or you may
damage the fuser door.
Pull the jammed paper out.8.
If the jammed paper does not move when you pull, push the two blue pressure levers up to loosen the
paper, and then remove it.
Return the levers, fuser door, and duplex guide to their original position.9.
Close the rear door.10.
Open and close the front cover.11.
Printing automatically resumes.
Duplex Jam
1.
