Core3(conf-router_rip)#network 192.168.2.0
Core3(conf-router_rip)#network 10.11.30.0
Core3(conf-router_rip)#network 10.11.20.0
Core3(conf-router_rip)#show config
!
router rip
network 10.0.0.0
network 192.168.1.0
network 192.168.2.0
version 2
Core3(conf-router_rip)#
Core 3 RIP Output
The examples in this section show the core 2 RIP output.
• To display Core 3 RIP database, use the show ip rip database command.
• To display Core 3 RIP setup, use the show ip route command.
• To display Core 3 RIP activity, use the show ip protocols command.
Examples of the show ip Commands to View Learned RIP Routes on Core 3
The following example shows the show ip rip database command to view the learned RIP routes on Core 3.
Core3#show ip rip database
Total number of routes in RIP database: 7
10.11.10.0/24
[120/1] via 10.11.20.2, 00:00:13, GigabitEthernet 3/21
10.200.10.0/24
[120/1] via 10.11.20.2, 00:00:13, GigabitEthernet 3/21
10.300.10.0/24
[120/1] via 10.11.20.2, 00:00:13, GigabitEthernet 3/21
10.11.20.0/24 directly connected,GigabitEthernet 3/21
10.11.30.0/24 directly connected,GigabitEthernet 3/11
10.0.0.0/8 auto-summary
192.168.1.0/24 directly connected,GigabitEthernet 3/23
192.168.1.0/24 auto-summary
192.168.2.0/24 directly connected,GigabitEthernet 3/24
192.168.2.0/24 auto-summary
Core3#
The following command shows the show ip routes command to view the RIP setup on Core 3.
Core3#show ip routes
Codes: C - connected, S - static, R - RIP,
B - BGP, IN - internal BGP, EX - external BGP,LO - Locally Originated,
O - OSPF, IA - OSPF inter area, N1 - OSPF NSSA external type 1,
N2 - OSPF NSSA external type 2, E1 - OSPF external type 1,
E2 - OSPF external type 2, i - IS-IS, L1 - IS-IS level-1,
L2 - IS-IS level-2, IA - IS-IS inter area, * - candidate default,
> - non-active route, + - summary route
Gateway of last resort is not set
Destination Gateway Dist/Metric Last Change
----------- ------- ----------- -----------
R 10.11.10.0/24 via 10.11.20.2, Gi 3/21 120/1 00:01:14
C 10.11.20.0/24 Direct, Gi 3/21 0/0 00:01:53
C 10.11.30.0/24 Direct, Gi 3/11 0/0 00:06:00
R 10.200.10.0/24 via 10.11.20.2, Gi 3/21 120/1 00:01:14
R 10.300.10.0/24 via 10.11.20.2, Gi 3/21 120/1 00:01:14
C 192.168.1.0/24 Direct, Gi 3/23 0/0 00:06:53
C 192.168.2.0/24 Direct, Gi 3/24 0/0 00:06:26
Core3#
Routing Information Protocol (RIP)
679
