The following example shows the show ip protocols command to show the RIP conguration activity on Core 3.
Core3#show ip protocols
Routing Protocol is "RIP"
Sending updates every 30 seconds, next due in 6
Invalid after 180 seconds, hold down 180, flushed after 240
Output delay 8 milliseconds between packets
Automatic network summarization is in effect
Outgoing filter for all interfaces is
Incoming filter for all interfaces is
Default redistribution metric is 1
Default version control: receive version 2, send version 2
Interface Recv Send
GigabitEthernet 3/21 2 2
GigabitEthernet 3/11 2 2
GigabitEthernet 3/24 2 2
GigabitEthernet 3/23 2 2
Routing for Networks:
10.11.20.0
10.11.30.0
192.168.2.0
192.168.1.0
Routing Information Sources:
Gateway Distance Last Update
10.11.20.2 120 00:00:22
Distance: (default is 120)
Core3#
RIP Conguration Summary
Examples of Viewing RIP Conguration on Core 2 and Core 3
The following example shows viewing the RIP conguration on Core 2.
!
interface GigabitEthernet 2/1
ip address 10.11.10.1/24
no shutdown
!
interface GigabitEthernet 2/3
ip address 10.11.20.2/24
no shutdown
!
interface GigabitEthernet 2/4
ip address 10.200.10.1/24
no shutdown
!
interface GigabitEthernet 2/5
ip address 10.250.10.1/24
no shutdown
router rip
version 2
10.200.10.0
10.300.10.0
10.11.10.0
10.11.20.0
The following example shows viewing the RIP conguration on Core 3.
!
interface GigabitEthernet 3/1
ip address 10.11.30.1/24
no shutdown
680
Routing Information Protocol (RIP)
