Chapter 4 Parameters|
Revision August 2008, 03VE, SW V2.04 4-19
Pr. Explanation Settings
Factory
Setting
VF VFPG SVC FOCPG TQRPG
08-32
Tension PID P2 0.0~1000.0 50.0
○ ○ ○ ○ ○
08-33
Tension PID I2 0.00~500.00 sec 1.00
○ ○ ○ ○ ○
08-34
Reserved
08-35
PID/Line Speed Output
Status
0: Positive output
1: Negative output
0
○ ○ ○ ○ ○
08-36
Tension/Line Speed PID
Output Limit
0~100.00% (according to Pr,01-00) 20.00
○ ○ ○ ○ ○
08-37
Source of Line Speed
Input Command
0: Disable
1: Analog input (Pr. 03-00~03-02 is set to 12 line speed)
2: RS-485 communication setting (Pr.08-41)
3: Pulse input (Pr.08-40)
4: DFM-DCM pulse input (Pr.02-18)
0
○ ○ ○ ○ ○
08-38
Max. Line Speed 0.0~3000.0m/min 1000.0
○ ○ ○ ○ ○
08-39
Min. Line Speed 0.0~3000.0m/min 0.0
○ ○ ○ ○ ○
08-40
Pulse Number for Each
Meter
0.0~6000.0 0.0
○ ○ ○ ○ ○
08-41
Current Line Speed 0.0~3000.0m/min 0.0
○ ○ ○ ○ ○
08-42
Source of Reel Diameter 0: Calculated by line speed
1: Calculated by integrating thickness (encoder is on
reel shaft)(Pr.08-49~51, Pr.10-15)
2: Calculated by integrating thickness (encoder is on
motor)(Pr.08-23~08-24, 08-50~08-51, 10-00~10-01)
3: Calculated by analog input (Pr.03-00~03-02 is set to
13)
0
○ ○ ○ ○ ○
08-43
Max. Reel Diameter 1.0~6000.0mm 6000.0
○ ○ ○ ○ ○
08-44
Empty Reel Diameter 1.0~6000.0mm 1.0
○ ○ ○ ○ ○
08-45
Source of Initial Reel
Diameter
0: RS-485 communication setting (Pr.08-46)
1: Analog input (Pr.03-00-Pr.03-02 is set to 13)
0
○ ○ ○ ○ ○
08-46
Initial Reel Diameter 1.0~6000.0mm 1.0
○ ○ ○ ○ ○
08-47
Initial Reel Diameter 1 1.0~6000.0mm 1.0
○ ○ ○ ○ ○
08-48
Initial Reel Diameter 2 1.0~6000.0mm 1.0
○ ○ ○ ○ ○
08-49
Number of Pulse per
Revolution
1~10000ppr 1
○ ○ ○ ○ ○
08-50
Coil Number for Each
Layer
0.001~60.000mm 1.000
○ ○ ○ ○ ○
08-51
Material Thickness 0.001~60.000mm 1.000
○ ○ ○ ○ ○
08-52
Filter Time of Reel
Diameter
0.00 to 100.00 seconds 1.00
○ ○ ○ ○ ○
08-53
Auto Compensation of
Reel Diameter
0: Disable
1: Enable
1.00
○ ○ ○ ○ ○
08-54
Current Reel Diameter 1.0~6000.0mm 1.0
○ ○ ○ ○ ○
08-55
Smart Start 0: Disable
1: Enable
2: In unwind mode, rewind in reverse direction
1
○ ○ ○ ○ ○
08-56
Switch Level for Smart
Start and PID function
0.0~100.0% (according to Pr.08-26) 15.0
○ ○ ○ ○ ○
08-57
Frequency for Smart Start 0.00~600.00Hz 2.00
○ ○ ○ ○ ○
08-58
Accel. Time for Smart Start 0.01~600.00 seconds 3.00
○ ○ ○ ○
08-59
Broken Belt Detection 0: Disable
1: Enable
0
○ ○ ○ ○
08-60
Min. Line Speed of Broken
Belt Detection
0.0~3000.0m/min 0.0
○ ○ ○ ○
08-61
Allowance Error of Line
Speed of Broken Belt
Detection
1.0~6000.0mm 100.0
○ ○ ○ ○
08-62
Detection Time of Broken
Belt
0.00~100.00 sec 1.00
○ ○ ○ ○
08-63
Allowance Error Level of
Tension/Line Speed PID
Feedback
0~100% 100
○ ○ ○ ○
08-64
Allowance Error Detection
Time of Tension PID
Feedback
0.0~10.0 sec 0.5
○ ○ ○ ○
