Airplane Description DA 62 AFM
- FLC (Flight level change mode on/off)
- NOSE UP and NOSE DN (Vertical mode reference change)
- YD (Yaw damper on/off)
- This GDU is installed as the MFD.
- Servos with autopilot processing logic in the pitch, roll, yaw and pitch trim control
systems
- Servo mounts and brackets
- Flight director processing logic in the GIAs
- Control stick-mounted manual electric trim (MET) switch (split switch) for pitch trim
- Control stick-mounted trim interrupt and autopilot disconnect switch
- Control stick-mounted CWS (control wheel steering) switch
- Remote-mounted go-around switch (on the left side of the power lever knob)
- PFD/MFD mounted altitude preselect knob (ALT)
- PFD/MFD mounted heading select knob (HDG)
Flight director commands and autopilot modes are displayed on the PFD. Full AFCS
functionality is only available with both displays operating, and will disconnect under certain
reversionary conditions.
Upon initial system power-up, the system undergoes a preflight test. At the end of the
test, the autopilot disconnect tone sounds and the PFT and AFCS annunciations are
removed. Successful completion of the preflight test is required for the autopilot and
manual electric trim to engage.
Page 7 - 88 Rev. 0 11-Jan-2019 Doc. No. 11.01.05-E
