DA20-C1 Flight Manual Weight and Balance
Doc # DA202-C1 April 16, 2009 Page 6 - 13
Revision 24 DOT Approved
Equipment List
Item
Number
Part Description,
Manufacturer Part/Model No.
Weight
lbs (kg)
Arm
in (m)
22-001 Autopilot Turn Coordinator/Roll Computer 2.2 -16.4
S-TEC 01260-12-0-14 (1.0) (-0.42)
22-
(0.5) (-0.68)
002 Autopilot Pitch Computer
S-TEC 01261-54-14
1.1 -27.4
22-003 Autopilot Roll Servo 2.9
(1.3)
+43.5
(+1.11) S-TEC 0105-R2
22- vo 2.9
(1.3)
+43.5
(+1.11)
004 Autopilot Pitch Ser
S-TEC 0107-P4
23- +64.0
(+1.63)
001 GPS Antenna
King KA 92
0.4
(0.1)
23-002 Intercom
PS Engineering PM501
0.5
(0.2)
-15.5
(-0.39)
23-003 Nav / Com
Bendix/King KX 125
3.9
(1.8)
-20.5
(-0.52)
23-004 +43.5
(+1.11)
VHF Comm Antenna
Comant CI 122
0.5
(0.2)
23-005 -16.4
(-0.42)
Audio Panel
Bendix/King KA 134
0.8
(0.4)
23-006 -17.2
(-0.44)
Audio Panel w/ Marker Receiver
Bendix/King KMA 24
1.7
(0.8)
23-007
ing KX 155 (2.5)
-19.5
(-0.49)
Nav / Com w/ GS
Bendix/K
5.5
23-008 GPS/Comm
Bendix/King KLX 135A
4.4
(2.0)
-20.5
(-0.52)
23-009 GPS Antenna
Garmin GA56
0.4
(0.1)
+64.0
(+1.6)
23-010 GPS Antenna
Garmin GPS 150
0.2
(0.1)
-20.5
(-0.52)
23-011 Audio Panel w/Marker Receiver
PMA 6000
0.8
(0.4)
-17.2
(-0.44)
23-012 Audio Panel
Garmin GMA 340
1.0
(0.4)
-20.5
(-0.52)
23-013 Com
Bendix/King KY97A
2.8
(1.3)
-20.5
(-0.52)
23-014 Com
Icom IC A200 TSO
2.4
(1.1)
-20.5
(-0.52)
23-015 Com
GARMIN AT SL 40
2.1
(0.95)
-20.5
(-0.52)
24-001 Ammeter
VDO 190-031SB
0.2
(0.1)
-16.4
(-0.42)
24-002 EPU Kit (S/N C0001-C0148, C0150)
Diamond Service Bulletin # DAC1-24-02
4.5
(2.0)
+45.6
(+1.16)
24-003 Battery, GIL G-35M
Diamond Service Bulletin # DAC1-24-03
26.3
(11.9)
+57.5
(+1.46)
