DA20-C1 Flight Manual Supplement 7
Doc # DA202-C1 April 16, 2009 Page S7 - 4
4.4.18. Auxiliary Tank Fuel Transfer
NOTE
It is recommended to transfer fuel in level cruise flight.
1. Main fuel tank. less than 3/4 full
2. Auxiliary fuel tank indicator Full
3. Fuel Transfer switch ON
4. Transfer time 10 minutes
5. Auxiliary fuel tank indicator Empty
6. Main fuel tank 1/5 capacity increase
7. Fuel Transfer switch OFF
5. PERFORMANCE
There is no change in airplane performance with the Auxiliary Fuel Tank system installed.
6. WEIGHT AND BALANCE
The installation (including unusable fuel) adds 10.6 lbs (4.8 kg) of weight at 32.4 in (0.823 m)
moment arm.
Figure 1. Auxiliary Fuel Moment Chart
Revision 24 DOT Approved
