DA20-C1 Flight Manual
Supplement 13
Doc # DA202-C1 April 06, 2010 Page S13 - 5
Revision 25 DOT Approved
2.7 Placards
The placards shown below pertain only to the instrument panel with Garmin G500 Integrated
Display and must be installed:
1. Switches on the instrument panel below the GDU 620 display
a.
b.
2. On the flap controller
3. Power setting below the instrument panel
4. On the fuel quantity indicator
