7.3.3. Flap Position Indicator
The current flap position is indicated by three control lights beside the flap operating switch.
Wing Flap Position Light Degree
CRUISE green 0°
T/O yellow 15°
LDG yellow 45°
When two lights are illuminated at the same time, the flaps are in-between positions.
7.3.4. Pedal Adjustment
NOTE
The pedals may only be adjusted on the ground.
The pedals for rudder and brakes are unlocked by pulling the T-grip located in front of the
rudder pedal sledge tubes.
NOTE
Pull T-grip straight back. Do not pull upwards.
Forward adjustment: Push both pedals forward with your feet while pulling lightly
on the T-grip to disengage the latch.
Backward adjustment: Pull pedals backward to desired position by pulling on
T-grip.
NOTE
After the T-grip is released, push the pedals forward with your feet
until they lock in place.
