DA20-C1 Flight Manual
Description
Doc # DA202-C1 April 16, 2009 Page 7 - 8
Revision 24
7.4.1. Flight Instruments
The flight instruments are installed on the pilot's side of the instrument panel.
7.4.2. Cabin Heat
The cabin heat and defrost system, directs ram air through the exhaust heat shroud into the
cabin heat valve. The warm air is then directed to the window defrosting vents and to the cabin
floor as selected by the Floor/Defrost lever.
The cabin heat selector, located in the center console, is used to regulate the flow of heated air.
Lever down = cabin heat FULL ON
The Floor/Defrost lever directs the heated air to the defrost and floor vents.
Lever down = all cabin heat to Floor
7.4.3. Cabin Air
The cabin aeration is controlled by two adjustable air-vent nozzles. The two sliding windows in
the canopy can be opened for additional ventilation.
