DA20-C1 Flight Manual Limitations
Doc # DA202-C1 April 16, 2009 Page 2 - 3
Revision 24 DOT Approved
2.4. POWER PLANT LIMITATIONS
2.4.1. Engine
1. Engine Manufacturer : Teledyne Continental Motors
2. Engine Type Designation : IO-240-B
3. Engine Operating Limitations
Max. T/O Power (5 min.) : 125 BHP / 93.2 kW
Max. Permissible T/O RPM : 2800 RPM
Max. Continuous Power : 125 BHP / 93.2 kW
Max. Permissible Continuous RPM : 2800 RPM
4. Oil Pressure
Minimum : 10 psi (1.5 bar)
Maximum : 100 psi (6.9 bar)
Ambient temperature below 32ºF
(0ºC), Full power operation oil
pressure 70 psi max
Normal Operating : 30 psi (2.1 bar) to 60 psi (4.1 bar)
5. Intentionally left blank
6. Oil Temperature
Minimum : 75°F (24°C) Full power operation,
oil pressure normal 100ºF (38ºC)
Maximum : 240ºF (115°C)
