DA20-C1 Flight Manual
Supplement 13
Doc # DA202-C1 April 06, 2010 Page S13 - 4
2.3 AHRS Operational Area
The AHRS used in the G500 is limited in its operational area. Operations are prohibited
north of 72 degrees North and south of 70 degrees South latitudes and in the following
four regions:
1. North of 65 degrees North latitude between longitude 75 degrees West and
120 degrees West
2. North of 70 degrees North latitude between longitude 70 degrees West and
128 degrees West
3. North of 70 degrees North latitude between longitude 85 degrees East and
114 degrees East
4. South of 55 degrees South latitude between longitude 120 degrees East and
165 degrees East
Loss of G500 heading and attitude may occur beyond these regions, but this will not
affect the GPS track.
2.4 Navigation Angle
The GDU 620 Navigation Angle can be set to either True or Magnetic on the AUX page.
The Navigation Angle defines whether the GDU 620 headings are referenced to True or
Magnetic North. The Navigation Angle set in the GDU 620 must match that which is set
on the GNS navigator interfaced to the unit.
2.5 Aerobatic Maneuvers
Conducting aerobatic maneuvers may cause the attitude information displayed on the
G500 to be incorrect or temporarily removed from the display.
2.6 Kinds of Operation
The aircraft with the Garmin G500 installed is limited to Day/Night VFR operations only.
The table below lists the minimum fully functional G500 system Elements required for
VFR operations.
Equipment Number
Installed/Required
Primary/Multi Flight Display 1 or 2
Air Data Computer (ADC) 1 or 2
Standby Airspeed Indicator 1
Standby Altimeter 1
Magnetic Compass 1
Revision 25 DOT Approved
