Diamond DA20-C1 - Major Instruments and Controls

DA20-C1 Flight Manual
Supplement 13
Doc # DA202-C1 April 06, 2010 Page S13 - 19
Major Instruments and Controls
1. Flap Speeds 9. Engine RPM
2. Master Switch Panel 10. Air Speed Indicator
- AVIONICS MASTER 11. Auto Selector
- FUEL PUMP Switch 12. NAV/COM GPS
- GEN/BAT Switch 13. Altimeter
3. Fuel Prime 14. VHF COM
4. Ignition Switch 15. Magnetic Compass
5. Instrument Light Switch 16. Exhaust Gas Temperature (EGT)
6. Light Switch Panel 17. Fuel Pressure Indicator
- MAP 18. Cylinder Head Temperature (CHT)
- STROBE Light Switch 19. Oil Temperature Indicator
- POSITION 20. Fuel Quantity Indicator
- TAXI Light Switch 21. Hobbs Hourmeter
- LANDING Light Switch 22. 14 VDC Aux Power Outlet
- Optional Switch 23. Circuit Breaker Panel
- EPU* 24. Oil Pressure Indicator
- PITOT* 25. Voltmeter
- Auto Pilot* 26. Ammeter
7. Trim Indicator
8. GDU 620 Display
Note: Items marked * are optional
- EPU
- Auto Pilot
Revision 25 DOT Approved
