DA20-C1 Flight Manual General
Doc # DA202-C1 April 06, 2010 Page 1 - 4
Revision 25
1.5. DIMENSIONS
1.5.1. Overall Dimensions
Span: 35 ft 8 in (10.87 m)
Length: 23 ft 6 in (7.17 m)
Height: 7 ft 2 in (2.19 m)
1.5.2. Wing
Airfoil: Wortmann FX 63-137/20 HOAC
Wing Area: 125 sq ft (11.6 m2)
Mean Aerodynamic Chord (MAC): 3 ft 6.9 in (1.09 m)
Aspect Ratio: 10.0
Dihedral: +4° nominal
Sweep of Leading Edge: +1° nominal
1.5.3. Horizontal Stabilizer
Angle of Incidence : -4° ± 0.25°
Span: 8 ft 9 in (2.66 m)
1.5.4. Landing Gear
Track: 6 ft 3 in (1.90 m)
Wheel Base: 5 ft 6 in (1.68 m)
Tire Size: Nose: 5.00-4, 6 ply
Main: 5.00-5, 6 ply
Tire Pressure: Nose: 26 psi (1.8 bar)
Main: 33 psi (2.3 bar)
